QuantaSep® Details

*General QuantaSep Information: Specifications | FAQ | Presentation

The QuantaSep® 100 pilot/production chromatography system for fluid handling and control is composed of three modules, integrated into a single cabinet with dimensions of 30" width x 24" depth x 18" height and weighing 125 lbs.

  • Automates buffer delivery, column switching, fraction collection, based on UV, pH and conductivity
  • Graphical, intuitive software "dashboard" for easy operating and training
  • Automated GMP reports
    Complete batch reports
    Event and alarm logs
    Chromatograms and calibration history
    Data Archival and Security
  • Sanitary Flow Path
    Low system volume
    Minimal dead legs
    Precision Hardware
    Wier diaphragm valves
    Positive displacement pumps
    Large dynamic flow range
    100:1 turndown ratio for accurate gradients
  • Sensors
    UV, pH, and conductivity sensors
    Integrated flow cell
    Optional precolumn pH, and conductivity sensors
    Optional second 254 nm UV capability
    Pressure, temperature, air, leak
  • Safety features
    "Active air trap" minimizes "bubble trap dilution"
    Optional precolumn filter with differential pressure sensors
    Leak and pressure alarms
    Built in safety interlocks
    Software method checks
    Software security prevents unauthorized operation and tampering

The QuantaSep® Family

To meet the growing need for cGMP compatible sanitary purifications, Sepragen has developed a family of 6 systems designed to provide purification capability at different scales. All systems are scalable, and use the same design philosophy and software. They all automate many routine tasks so that mission critical project deadlines can be met. Clinical production capacity can be scaled up quickly within existing space and headcount limitations.

QuantaSep® Specifications

QSep
100
QSep
1000
QSep
1000LX
QSep
1800
QSep
5000
QSep
10000
Flow Range
1-100 ml/min
10-1000 ml/min
1-100 ml/min
& 10-1000 ml/min
20-1800 ml/min
50ml- 5L/min
100ml- 10L/min
User Selectable
Buffers
12
12
2x12
12
8
8
User Selectable
Columns
3
3
2x3
3
1
1
User Selectable Fractions
10
10
2x10
10
6
6
Hold Up Volume
7ml
120 ml
Low:
18 ml
High:
120 ml
120 ml
~650 ml
1.2 L
Component Footprint
21"x26" x15"
21"x26" x15"
21"x26" x15"
21"x26" x15"
Mobile Unit;
22"x27" x46.5"
Mobile Unit;
22"x27" x46.5"
Gradient Capability
5-95%
5-95%
5-95%
5-95%
5-95%
5-95%
Pressure Rating
100 psi
50 psi
50 psi
50 psi
50 psi
50 psi
Tubing
1/16" ID
1/4" ID
Low:
1/16" ID
High:
1/4" ID
3/8" ID
1/2" ID
5/8" ID
Chemical Compatability
1M Sodium Hydroxide
19% Alcohol
Operating Temperature
4oC-25oC
Utilities Requirement
Power Requirement
110V
110/220V; 6Å
Air Requirement
Not Required
90 psi
Wetted Materials of Construction
Tubing
Silicone, Polyethylene, and Polypropylene
Valves & Fittings
Polypropylene
Diaphragms
PTFE
Sensor Components
Glass, Quartz, 316L Stainless Steel
Components Specifications
UV Sensor
280 nm 0-2 Au
254 nm 0-2 Au (Optional)
Conductivity Sensor
0-200 ms
pH Sensor
1-14 pH
Air Bubble
Eject Size
> 0.20"
Pressure Sensor
0-100 psi
Leak Sensor
5 ml leak volume
Warranty, Installation and Support
All QuantaSep®'s are backed by Sepragen's one year limited warranty. Installation and training, along with IQ/OQ are preformed by Sepragen Service Group. Preventative maintenance and Total maintenance service is provided at additional cost. Validation support packages are also available.
